RE: [PSUBS-MAILIST] K250 on eBay.



Hi Cliff,



3 coats of the epoxy, 3 hours between coats. The polyurethane was applied immediately after the epoxy tacked up. This gives better adhesion because the solvents in the topcoat don’t bite into the hardened epoxy very well, even if it is sanded. I usually use awlgrip as a topcoat but actually used PPG “Delfleet” on the Great White because it is available in metallic and is extremely hard. Two coats color and one coat clear for extra UV protection.



I keep emergency air in a separate bottle and keep the valve “off” to avoid a possible leak during the dive.



Greg Cottrell

Project Manager





greg@precisionplastics.com

http://www.precisionplastics.com



P please consider the environment before printing this email


From: owner-personal_submersibles@psubs.org [mailto:owner-personal_submersibles@psubs.org] On Behalf Of Cliff Redus
Sent: Tuesday, October 12, 2010 2:03 PM
To: personal_submersibles@psubs.org
Subject: Re: [PSUBS-MAILIST] K250 on eBay.



Greg, a couple of questions on the paint job.  How many primer coats did you spray with the Interlux2000e? What brand of marine polyurethane did you use and how many coats? Did you sand between primer and top coat?  If yes, what grit size?   Do you have a painting procedure document that you could share?



I am assuming that since you are not using a second stage regulator on air system, that you did not install a BIBS.  Is this correct or do you dive with spare tank/regulator for emergencies?


Cliff


From: Greg Cottrell <greg@precisionplastics.com>
To: personal_submersibles@psubs.org
Sent: Tue, October 12, 2010 11:26:46 AM
Subject: RE: [PSUBS-MAILIST] K250 on eBay.

Thanks Frank. It was a fun project. Dan Lance also contributed a whole lot of welding. I was surprised to find that the early k-250s didn’t use any stainless parts or even 0-rings. All the thru-hulls were carbon steel pipe with bronze jam nuts. We cut them all out and replaced them with 316 ss. There was no flood valve- just a 2” removable threaded pipe cap.

The sub now has flood valves on each side where the old motors exited the hull. All electric power goes through a removable SS plate aft. The MBTs are saddle style. There is a flip up seat so a second person can lie on the floor. The entire hull was sand/soda blasted and coated with Interlux 2000e and top coated with marine polyurethane. The air system has no regulator- it HP all the way- all valves and flex lines are rated for 6000 psi. The tanks can be remotely filled with a HP whip.



Greg Cottrell

Project Manager





greg@precisionplastics.com

http://www.precisionplastics.com



P please consider the environment before printing this email


From: owner- personal_submersibles@psubs.org [mailto:owner- personal_submersibles@psubs.org ] On Behalf Of ShellyDalg@aol.com
Sent: Tuesday, October 12, 2010 10:53 AM
To: personal_submersibles@psubs.org
Subject: Re: [PSUBS-MAILIST] K250 on eBay.



Thanks Ian and Greg.  I enjoy following Scott's activities after seeing his presentation on " El Rojo Diablo "

Giant squids and especially octopi just fascinate me.

I'm sorry I missed his visit to the convention in Maine . I saw the short video and it looked like fun.

Greg......looks like you did a nice job on the K250 re-fit of Great White. I'll be watching for further adventures with this boat.

Frank D.
