Psub stuff. The whole rig was made right in the shop. Lot of talk about this battery and that battery these days, but those fourteen two-volt cells in a few gallons of oil were, and continue to be, very hard to beat for practical use. We never, ever had a problem while I was there. And only serviced them annually! Vance -----Original Message----- From: greg@precisionplastics.com To: personal_submersibles Sent: Fri, Jun 10, 2011 4:56 am Subject: RE: Re: [PSUBS-MAILIST] jettisoning battery pods or other ballast I made one of the acrylic covers for the JSL battery housing and looked over the release system with great interest. It’s a pretty sweet set up.
Greg Cottrell Project Manager
http://www.precisionplastics.com
P please consider the environment before printing this email From: owner-personal_submersibles@psubs.org [mailto:owner-personal_submersibles@psubs.org] On Behalf Of vbra676539@aol.com
Exactly the method used
on the JSLs for the battery box release. The cam holds a suspension rod under
compressive tension. Meaning the battery/chassis connection is strong and
immobile. When wound open, the hook is rotated open side down, guaranteeing release.
Back of box suspended on bronze bushings. The front is released, battery swings
in a short arc down and aft and AWAY you go. Realy good solution. Press the weight tight to the hull. "Jens Laland" <laland@artematrix.org> schrieb: > Jon > > Here are two sketches (from Hans Techel's book) of a quick release system > as done on early types of naval submarines when those were still using > drop keels, ref > > http://traktoria.org/files/personal_submarine/drop-keel/Sicherheitsgewicht.jpg > > Best regards, > Jens Laland > > > > > ************************************************************************ > ************************************************************************ > ************************************************************************ > The personal submersibles mailing list complies with the US Federal > CAN-SPAM Act of 2003. Your email address appears in our database > because either you, or someone you know, requested you receive messages > from our organization. > > If you want to be removed from this mailing list simply click on the > link below or send a blank email message to: > removeme-personal_submersibles@psubs.org > > Removal of your email address from this mailing list occurs by an > automated process and should be complete within five minutes of > our server receiving your request. > > PSUBS.ORG > PO Box 53 > Weare, NH 03281 > 603-529-1100 > ************************************************************************ > ************************************************************************ > ************************************************************************ > > ************************************************************************ ************************************************************************ ************************************************************************ The personal submersibles mailing list complies with the US Federal CAN-SPAM Act of 2003. Your email address appears in our database because either you, or someone you know, requested you receive messages from our organization. If you want to be removed from this mailing list simply click on the link below or send a blank email message to: removeme-personal_submersibles@psubs.org Removal of your email address from this mailing list occurs by an automated process and should be complete within five minutes of our server receiving your request. PSUBS.ORG PO Box 53 Weare, NH 03281 603-529-1100 ************************************************************************ ************************************************************************ ************************************************************************ |
